AI Agent with DeepSeek-R1, AutoGen and MAX Serve

This recipe demonstrates how to build AI agents using:

• DeepSeek-R1-Distill-Qwen-7B model that runs on GPU
• AutoGen framework for multi-agent conversations
• MAX Serve for efficient model serving and inference
• Rich Python library for beautiful terminal interfaces

We'll create two example applications that showcase:

• A conversational AI assistant with thought process visibility leveraging DeepSeek thinking process
• A collaborative screenplay development system with multiple specialized agents

The patterns demonstrated here can be adapted for various agent-based applications like:

• Customer service automation
• Educational tutoring systems
• Creative writing assistants
• Technical support agents
• Research assistants

Requirements

Please make sure your system meets our system requirements.

To proceed, ensure you have the magic CLI installed:

curl -ssL https://magic.modular.com/ | bash






or update it via:

magic self-update






GPU requirements

Structured output with MAX Serve requires GPU access. For running the app on GPU, ensure your system meets these GPU requirements:

• Supported GPUs: NVIDIA A100 (optimized), A10G, L4, or L40
• NVIDIA Drivers: Installation guide here
• NVIDIA Container Toolkit: Installation guide here

Quick start

1. Download the code for this recipe using git:

   git clone https://github.com/modular/max-recipes.git
   cd max-recipes/deepseek-qwen-autogen-agent






2. Run the MAX Serve server via in a terminal:

   magic run server






3. In a new terminal, run either example:

   • For the chat agent:

     magic run chat_agent






   • For the screenplay development team:

     magic run screenplay_agents






The agents will be ready when you see the welcome message in your terminal.

Quick demos

Chat agent with visible thinking

Demo shows:

• Starting a conversation with the AI
• AI's thinking process displayed in yellow panels
• Final responses in green panels
• Multiple turns of natural conversation
• Example of complex reasoning task

Screenplay development team

Demo shows:

• User providing initial scene idea
• Screenwriter creating first draft
• Story Critic analyzing and improving
• Dialogue Expert polishing the scene
• Full collaborative workflow between agents

Technical deep dive

Single agent chat implementation

client = OpenAIChatCompletionClient(
    model="deepseek-ai/DeepSeek-R1-Distill-Qwen-7B",
    base_url=LLM_SERVER_URL,
    api_key=LLM_API_KEY,
    model_info={
        "name": "deepseek-ai/DeepSeek-R1-Distill-Qwen-7B",
        "family": "deepseek",
        "pricing": {"prompt": 0.0, "completion": 0.0},
    },
    temperature=0.7,  # Adjust for more/less creative responses
    max_tokens=4096,  # Adjust for longer conversation
)

assistant = AssistantAgent(
    name="assistant",
    model_client=client,
    system_message="You are a helpful assistant.",
)






Key features:

• Uses DeepSeek-R1 model through MAX Serve
• Configurable temperature for response creativity
• Adjust max_tokens for longer conversations

# Keep track of conversation history
conversation_history = []

# Add user message to history
conversation_history.append(TextMessage(content=user_input, source="user"))

# Get AI response with full context
response = await assistant.on_messages(
    conversation_history,  # Pass entire history
    CancellationToken(),
)
conversation_history.append(response.chat_message)






Benefits:

• Maintains context across multiple turns
• Enables coherent multi-turn conversations
• Preserves conversation state

The agent separates its thinking from its final response:

content = response.chat_message.content
parts = content.split('')
if len(parts) > 1:
    thinking = parts[0].strip()
    final_answer = parts[1].strip()
else:
    thinking = "No explicit thinking process shown"
    final_answer = content.strip()






This allows users to see:

• The reasoning process
• Considered alternatives
• Decision-making steps

The chat interface uses Rich for enhanced visualization:

console.print(Panel(
    Markdown(thinking),
    border_style="yellow",
    title="[bold]💭 Thinking Process[/bold]",
    title_align="left"
))

console.print(Panel(
    Markdown(final_answer),
    border_style="green",
    title="[bold]🤖 Response[/bold]",
    title_align="left"
))






Features:

• Color-coded panels for different content types
• Markdown rendering for formatted text
• Clear separation of thinking and responses
• Status indicators during processing

Multi-agent screenplay development

The screenplay development system uses multiple specialized agents working together through round-robin conversation. Here's a detailed look at the implementation:

screenwriter = AssistantAgent(
    name="screenwriter",
    system_message="""You are an experienced screenwriter who creates engaging movie scenes and dialogue.
First think about the scene carefully. Consider:
- Setting and atmosphere
- Character development
- Plot progression
Then write a brief but vivid scene with clear stage directions and dialogue.""",
    model_client=client,
)

story_critic = AssistantAgent(
    name="story_critic",
    system_message="""You are a story development expert. Review the screenwriter's scene and think about:
- Plot coherence and dramatic tension
- Character motivations and arcs
- Theme development
Then provide:
1. An improved version of the scene
2. A list of specific improvements made and why they work better""",
    model_client=client,
)

dialogue_expert = AssistantAgent(
    name="dialogue_expert",
    system_message="""You are a dialogue specialist. Review both the original and improved scenes, then think about:
- Character voice authenticity
- Subtext and emotional depth
- Natural flow and rhythm
Then provide:
1. A final version with enhanced dialogue
2. A list of specific dialogue improvements made and their impact on the scene""",
    model_client=client,
)






Each agent has a specific role:

• Screenwriter: Creates initial scene drafts
• Story Critic: Improves plot and structure
• Dialogue Expert: Enhances character voices and interactions

agent_team = RoundRobinGroupChat(
    agents=[screenwriter, story_critic, dialogue_expert],
    max_turns=3,  # One turn for each agent
    speaker_selection_method="round_robin"
)






The round-robin chat ensures:

• Ordered turn-taking between agents
• Complete review cycle for each scene
• Collaborative improvement process

async for message in stream:
    if hasattr(message, 'content') and hasattr(message, 'source'):
        content = message.content
        source = message.source

        # Split thinking and contribution
        parts = content.split('')
        if len(parts) > 1:
            thinking = parts[0].strip()
            final_answer = parts[1].strip()
        else:
            thinking = "No explicit thinking process shown"
            final_answer = content.strip()

        # Display each agent's contribution
        console.print(Panel(
            Markdown(thinking),
            border_style="yellow",
            title=f"[bold]💭 {source} Thinking[/bold]",
            title_align="left"
        ))

        console.print(Panel(
            Markdown(final_answer),
            border_style="green",
            title=f"[bold]🎬 {source} Contribution[/bold]",
            title_align="left"
        ))






Features:

• Real-time display of each agent's process
• Clear attribution of contributions
• Separation of thinking and final output
• Rich formatting for readability

1. Initial Scene Creation

User: Write a scene about a reunion between old friends
Screenwriter: [Analyzes setting and characters]
Screenwriter: [Creates initial scene with dialogue]






2. Story Review and Enhancement

Story Critic: [Evaluates dramatic tension]
Story Critic: [Suggests structural improvements]






3. Dialogue Polish

Dialogue Expert: [Analyzes character voices]
Dialogue Expert: [Enhances dialogue authenticity]






You can adapt the screenplay system for different creative tasks:

1. Add Specialized Agents

technical_advisor = AssistantAgent(
    name="technical_advisor",
    system_message="""You ensure accuracy in specialized scenes...""",
    model_client=client
)






2. Modify Review Cycles

agent_team = RoundRobinGroupChat(
    agents=[...],
    max_turns=4,  # Add more revision cycles
)






3. Enhance Agent Specialties

system_message="""You are a genre specialist focusing on:
- Genre conventions
- Typical plot structures
- Character archetypes
..."""






Customizing for your use case

This recipe can be adapted for various applications:

1. Educational Tutoring

   • Add agents for different subjects
   • Implement knowledge assessment
   • Create personalized learning paths

2. Technical Support

   • Add agents for different technical domains
   • Implement troubleshooting workflows
   • Create solution verification steps

3. Research Assistant

   • Add agents for literature review
   • Implement data analysis
   • Create report generation

Troubleshooting

Common issues and solutions:

1. Server Connection Issues

   • Ensure MAX Serve is running (magic run server)
   • Check if the default port 8010 is available
   • Verify network connectivity

2. Agent Response Issues

   • Check system messages for clarity
   • Adjust max_turns for multi-agent scenarios
   • Verify conversation history handling

3. Performance Issues

   • Monitor GPU memory usage
   • Adjust batch sizes if needed
   • Consider reducing conversation history length

Conclusion

This recipe demonstrates how to:

• Build single and multi-agent systems with AutoGen
• Use DeepSeek-R1 and examine its thinking process
• Create beautiful terminal interfaces with Rich Python library
• Implement robust error handling
• Enable collaborative agent interactions

The patterns shown here provide a foundation for building your own agent-based applications.

Next steps

• Deploy your agents on AWS, GCP or Azure
• Explore MAX documentation for more features
• Join our Modular Forum and Discord community

Share your agent projects with us using #ModularAI on social media!
